Pita Bread Production Line
Complete design and 3D modeling of an automated pita bread production line — from conveyor systems and dough processing to cooling towers and industrial ovens, delivered as manufacturing-ready files.
Client Location
Turkey
Selected visuals only. Full technical documentation, manufacturing drawings, BOMs, and internal design files are not shown due to client confidentiality and NDA restrictions.
The Challenge
Design a complete, automated pita bread production line from concept to manufacture. The line needed to integrate multiple modules — dough handling, forming, baking, cooling, and conveying — into a single cohesive system with consistent mechanical interfaces, food-grade materials, and reliable operation.
The Approach
Modeled every module in SolidWorks as a complete 3D assembly — including the blue modular belt conveyor system, stainless steel dough processing unit with hopper, cooling tower with ventilation panels, industrial oven, and dryer/cooling conveyor. Each unit was designed for manufacturability with standard components, food-grade stainless steel construction, and safety handles. Full BOMs and technical drawings were prepared for every module.
The Outcome
Delivered a complete, manufacturing-ready production line package with all modules modeled in 3D CAD, full technical drawings, and BOMs. The modular design allowed each section to be manufactured and assembled independently before final line integration.
Project Info
Location
Turkey
Client
Food production client
Scope of Work
Deliverables
Tags
